A treatment result is recognised as confirmed only where instrumental measurements before and after treatment are available. Measurements are taken with the same instrument, under the same load mode, with running time in between; both values are entered in the protocol.
The list of controlled parameters is grouped by component type: for each parameter the unit, the measuring instrument and the measurement conditions are specified. The report form defines the protocol layout; the filled example shows the content of each field.
Measurement guideline: before applying the compound, take baseline values for the parameters of your component and record the instrument, mode and running time.
| what to measure | instrument | when and how |
|---|---|---|
| backlash in the mesh, mm | gear tooth gauge or feeler | for every stage |
| tooth thickness, mm | micrometer, template | on the same tooth; the measuring depth is recorded |
| shaft play, mm | dial indicator on a stand | before and after |
| bearing housing vibration, mm/s | vibration meter | in steady-state duty |
| drive current and power, A / kW | clamp meter | no load and working load |
71 cases in the catalogue for: reduction gearbox, gear drive, gearbox, driveshaft →
| what to measure | instrument | when and how |
|---|---|---|
| time to reach working pressure, s | stopwatch | from the same pressure to the same pressure |
| capacity, m³/min | flow meter, or calculated from time | in the same duty |
| oil pressure in the lubrication system, atm | pressure gauge | before and after |
| oil consumption through the lubricator, l/day | measuring vessel | over a day of operation |
| vibration and noise, mm/s and dBA | vibration meter, sound level meter | the same measuring points |
70 cases in the catalogue for: compressor, turbocompressor →
| what to measure | instrument | when and how |
|---|---|---|
| compression per cylinder, kgf/cm² | compression gauge | engine at operating temperature, every cylinder how to measure → |
| peak firing pressure, kgf/cm² | maximeter | at the same speed and controller position how to measure → |
| fuel consumption, l/100 km or kg/h | on-board metering, measuring tank | comparable periods of equal length |
| oil pressure, atm | pressure gauge | in the same duty |
| exhaust emissions, % and ppm | gas analyser | at idle |
99 cases in the catalogue for: diesel engine, petrol engine, cylinder-piston group →
| what to measure | instrument | when and how |
|---|---|---|
| run-out and play, mm | dial indicator | the same points |
| component temperature, °C | thermometer or pyrometer | in steady-state duty |
| vibration, mm/s | vibration meter | before and after |
| drive current, A | clamp meter | at idle |
84 cases in the catalogue for: bearings, slideways, friction pair →
One instrument, one duty, one point. The before and after measurements are taken with the same instrument, at the same load and at the same points: otherwise the difference reflects a difference of conditions, not the treatment result.
Running time between measurements. The “after” measurement is taken at the end of the full treatment cycle set by the component's procedure: from 30 to 700 operating hours, or from 1,500 to 4,000 km where the procedure sets mileage. Cycle lengths by component group are given in the pilot treatment timing table.
A second identical unit left untreated. Most cases in this catalogue have no control machine: the treated unit is compared against itself, before and after.
Cylinders of one engine wear differently, so their compression differs and is measured on each cylinder separately. Read the spread between cylinders, not only the average.
Take the first measurement on a decarbonised engine. Only then does it show the real condition rather than compression propped up by carbon: otherwise the gain looks smaller than it is.
Order of preparation:
Compounds and doses for decarbonising — in the procedure for your engine (industrial diesels, diesels under 30 l of oil, petrol engines): the names and doses there are the factory ones.
The form covers the fields most often left blank in the catalogue's reports. The filled example shows the content of each field; the plant in it is a stand-in.
Blank form, PDF · 4 pages (RU) Filled example, PDF (RU)
The dosing and operating regime during treatment is set out on the page Guarantees and limits. The full procedure, from preparing the system to the “after” measurements, is in Pilot treatment procedure.
Dose rate, number of stages and intervals are set by the component's procedure: the amount of compound is calculated from the oil or hydraulic fluid volume or from the dose-rate table. All of it is published in full: the procedure for your component — what to add and how many stages, the dose-rate table — the amount of gel by component. The printed instruction comes with the compound; if its revision differs from the page, the printed one prevails.
